| Frame |
Aluminum, 9x135mm QR, 24" |
| Fork |
SR Suntour XCT Air NLO, 70mm, 9X100 QR |
| Rear Shifter |
Shimano Cues SL-U4000, 9sp |
| Rear Derailleur |
Shimano Cues RD-U4000, 9sp, GS |
| Crankset |
Alloy 3pc, 152mm, 28T Narrow Wide |
| Bottom Bracket |
Sealed bearing, ST 68mm |
| Cassette |
Shimano Cues CS-LG300-9, 11-46T, 9sp |
| Chain |
KMC Z9 |
| Front Brake |
Tektro HD-M286, Resin Pads |
| Front Brake Rotor |
Tektro. 160mm rotor, 6-bolt |
| Rear Brake |
Tektro HD-M286, Resin Pads |
| Rear Brake Rotor |
Tektro. 160mm rotor, 6-bolt |
| Brake Levers |
Tektro HD-M286, Hydraulic 2-Finger Jr. Levers |
| Handlebar |
Alloy Jr. Riser, 600mm, 30mm Rise |
| Stem |
Alloy 40mm Length, 31.8mm Clamp |
| Seatpost |
Norco Alloy 27.2mm, 250mm length |
| Headset |
External Cup Ball Bearing, 1-1/8" EC 34 |
| Headset Spacer |
1x10mm , 2x5mm |
| Saddle |
Norco Jr XC, Steel Rail |
| Grips |
Norco Youth, 115mm Length |
| Pedals |
Jr. MTB Flat, 9/16" |
| Seatpost Clamp |
Norco Alloy Bolted, 34.9mm ID |
| Front Hub |
Formula DC-1420 , 9x100mm QR, 28h, 6-bolt |
| Rear Hub |
Formula DC-1425,10x135mm QR, HG, 28H, 6-bolt |
| Rims |
Aluminum DW, 28h, 24" MTB |
| Front Tire |
CY Trail, 24x2.25", Wire |
| Rear Tire |
CY Trail, 24x2.25", Wire |
| Spokes/Nipples |
Stainless Steel w/Brass Nipples |
| Weight |
12.04 kg (26.5 lbs) |
